Pick by function
Each device does one job. Take the ones the system needs, and add another when it needs more.
Plug-and-play battery electronics
One controller.
Any number of packs.
Plug-and-play edge devices for high-voltage battery safety and monitoring, by Lithostack™.
1 controller · n packs
Technology
Choose the functions. Plug them in.
Battery pack
Edge device — measures & reports
Central controller — decides
Battery connection
Shared network
We at Lithostack™ build off-the-shelf edge devices for high voltage battery monitoring.
Each one is plug-and-play:
it joins the same network, measures at the source, and reports to the central controller.
Advantages
Modular by design. Built to scale.
Each device is a server on the shared network: the central controller takes the safety decisions with the whole system in view, and the devices carry them out. They are Safety Elements out of Context, designed to the safety integrity level each function needs under ISO 26262 or IEC 61508, up to ASIL D. Each states the assumptions of use you confirm on integration.
Plug in
Hardware keying gives every device its address on the shared network.
Stack packs
More packs means only more edge devices, all reporting to one controller.
Products
The devices.
A device for each part of the system, all on one shared network.
Battery Junction Box
High voltage, pack current and isolation resistance measurement, with open/close control of up to four contactors.
In development ↗Battery Voltage Monitoring Board
Brick/Cell voltages and module temperatures from all the daisy-chained Battery Voltage Monitoring Boards along the pack.
Concept ↗Current Sensor
Pack current across the full operating range, from standby leakage to peak discharge.
Concept ↗Thermal Event Indication
Early detection of a thermal event inside the pack, reported to the central controller.
Concept ↗Where it fits
The same part, in any system.
Because a device assumes nothing about what it is fitted to, the same part goes into a vehicle, a grid installation or a data centre unchanged. Put several devices by Lithostack™ on one network and they cover the whole battery system.
- Automotive
- Hybrid and full-electric drivetrains, and the wider transport platforms built on them.
- Grid storage
- Grid-scale and industrial battery energy storage installations.
- Data centres
- Backup and peak-shaving storage in data centre power systems.
About
The team
Each member of the founding team at Lithostack™ has over a decade of engineering experience building safety-critical automotive ECUs. Between them they have carried products from concept through ISO 26262 qualification into series production. Their work spans battery management systems, high-power charger controllers, high-performance EV powertrains, high-voltage electronics, grid-scale energy storage, cell modelling and state estimation, and manufacturing.
Contact
Engineers who design the product will respond
Describe the pack, the controller it reports to and the signals you need measured, and we will tell you which devices cover it.
